FB 2810E4

Fully closed integrated design of machine head and controlling system are convenient to maintain, safer and more power saving.
The larger operation space facilitates the handing of large-area workpieces.
With the functions of auto trimming, auto back tacking, pneumatic presser foot lifting, integrated LED light and self-locked stitch length dial, it can make the normal sewing more comfortable and efficient.
It adopts new type electrical clamp device, so that can reduce the “nest” stitch phenomenon.
It can adjust the alternating amount of presser foot by manual through the knob.

Sewing fabrics such as imitation leather, artificial leather, bags, cushions, tents, fabric sofas, shoes, bags, gloves, etc.

Specification

Model No	FB 1510D-LG
Feeding System	Alternating presser foot, feed dog and needle feeding
Max sewing speed	2500 s.p.m.
Shutter diameter	θ 28mm
Applied needle	Dp x 17#18-#23
Thread size	Maximum thread 9 strands nylon
Max stitch length	9mm
Max Alternating presser foot	6.5mm (Manually adjusted by knob)
Max presser foot lifting height	16mm
Presser foot lifting function	Presser foot lifting by knee controller
Auto oil system	✓
Follow-up binding component	✓
Operating space	255 x 103mm

FB 1510D-AF/LG
Alternating presser foot, feed dog and needle feeding
2000 s.p.m.
θ 28mm
Dp x 17#18-#23
Maximum thread 9 strands nylon
9mm
6.5mm (Manually adjusted by knob)
16mm
Presser foot lifting height by air
✓
✓
255 x 103mm

Model No	FB 2810E4
Feeding System	Presser foot and feed dog feeding
Max sewing speed	2200 s.p.m.
Shutter diameter	θ 25mm
Applied needle	Dp x 17#11-#18
Max Stitch length	12mm
Max Alternating presser foot	5.5mm (Manually adjusted by knob)
Max presser foot lifting height	11mm
Auto trimming	✓
Auto oil system	✓
Auto back tacking	✓
Integrated LED light	✓
Operating space	365 x 150mm
